| 標準代號 | 規格號碼 | 材料號碼 | 記號 |
|---|---|---|---|
| CNS | 8701 | SFVAF1 | |
| JIS | G3203 | SFVAF1 | |
| ASTM | A182 | F1 | |
| ASTM | A336 | F1 | |
| CNS | 8701 | SFVAF2 | |
| JIS | G3203 | SFVAF2 | |
| CNS | 8701 | SFVAF5A | |
| JIS | G3203 | SFVAF5A | |
| ASTM | A336 | LF5 | |
| CNS | 8701 | SFVAF5B | |
| JIS | G3203 | SFVAF5B | |
| ASTM | A182 | F5 | |
| DIN | 1.7363 | 12CrMo19-5 | |
| CNS | 8701 | SFVAF5C | |
| JIS | G3203 | SFVAF5C | |
| ASTM | A336 | F5A | |
| DIN | 1.7368 | X12CrMo7 | |
| CNS | 8701 | SFVAF5D | |
| JIS | G3203 | SFVAF5D | |
| ASTM | A182 | F5A | |
| CNS | 8701 | SFVAF9 | |
| JIS | G3203 | SFVAF9 | |
| ASTM | A182 | F9 | |
| ASTM | A336 | F9 | |
| CNS | 8701 | SFVAF11A | |
| GB | 15CrMo | ||
| JIS | G3203 | SFVAF11A | |
| ASTM | A182 | F11Class2 | |
| ASTM | A336 | F11 | |
| DIN | 1.7335 | X12CrMo7 |
| 碳(C)% | 矽(Si)% | 錳(Mn)% | 磷(P)% | 硫(S)% | 鎳(Ni)% | 鉻(Cr)% | 鉬(Mo)% | 降伏強度(Mpa) | 抗拉強度(Mpa) | 伸長率(%) | 硬度HB |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ≦ 0.3 | ≦ 0.35 | 0.6~0.9 | ≦ 0.03 | ≦ 0.03 | 0.45~0.65 | ≧ 275 | 480~660 | ≧ 18 | |||
| ≦ 0.3 | ≦ 0.325 | 0.6~0.9 | ≦ 0.03 | ≦ 0.03 | ≧ 275 | 480~660 | ≧ 18 | ||||
| ≦ 0.28 | 0.15~0.35 | 0.6~0.9 | ≦ 0.045 | ≦ 0.045 | ≧ 275 | ≧ 485 | ≧ 20 | 143~192 | |||
| 0.2~0.3 | 0.2~0.35 | 0.6~0.9 | ≦ 0.025 | ≦ 0.025 | ≧ 275 | 485~660 | ≧ 20 | ||||
| ≦ 0.2 | ≦ 0.6 | 0.3~0.8 | ≦ 0.03 | 0.5~0.8 | 0.45~0.65 | ≧ 275 | 480~660 | ≧ 18 | |||
| ≦ 0.2 | ≦ 0.6 | 0.3~0.8 | ≦ 0.03 | 0.5~0.8 | 0.45~0.65 | ≧ 275 | 480~660 | ≧ 18 | |||
| ≦ 0.15 | ≦ 0.5 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 4~6 | 0.45~0.65 | ≧ 245 | 410~590 | ≧ 18 | ||
| ≦ 0.15 | ≦ 0.5 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 4~6 | 0.45~0.65 | ≧ 245 | 410~590 | ≧ 18 | ||
| ≦ 0.15 | ≦ 0.5 | 0.3~0.6 | ≦ 0.025 | ≦ 0.025 | 4~6 | 0.45~0.65 | ≧ 245 | 410~586 | ≧ 20 | ||
| ≦ 0.15 | ≦ 0.5 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 4~6 | 0.45~0.65 | ≧ 275 | 480~660 | ≧ 18 | ||
| ≦ 0.15 | ≦ 0.5 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 4~6 | 0.45~0.65 | ≧ 275 | 480~660 | ≧ 18 | ||
| ≦ 0.15 | ≦ 0.5 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | ≦ 0.5 | 4~6 | 0.45~0.65 | ≧ 275 | ≧ 485 | ≧ 20 | 143~217 |
| 0.08~0.15 | ≦ 0.5 | 0.3~0.6 | ≦ 0.025 | ≦ 0.02 | 4~6 | 0.45~0.65 | ≧ 390 | 590~740 | ≧ 17 | 175~220 | |
| ≦ 0.25 | ≦ 0.5 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 4~6 | 0.45~0.65 | ≧ 345 | 550~730 | ≧ 18 | ||
| ≦ 0.25 | ≦ 0.5 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 4~6 | 0.45~0.65 | ≧ 345 | 550~730 | ≧ 18 | ||
| ≦ 0.25 | ≦ 0.5 | ≦ 0.6 | ≦ 0.025 | ≦ 0.025 | ≦ 0.5 | 4~6 | 0.45~0.65 | ≧ 345 | 550~725 | ≧ 19 | |
| ≦ 0.15 | 0.5~1 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 6~8 | 0.45~0.65 | |||||
| ≦ 0.25 | ≦ 0.5 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 4~6 | 0.45~0.65 | ≧ 450 | 620~780 | ≧ 18 | ||
| ≦ 0.25 | ≦ 0.5 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 4~6 | 0.45~0.65 | ≧ 450 | 620~780 | ≧ 18 | ||
| ≦ 0.25 | ≦ 0.5 | ≦ 0.6 | ≦ 0.03 | ≦ 0.03 | 4~6 | 0.44~0.65 | ≧ 450 | ≧ 620 | ≧ 22 | 187~248 | |
| ≦ 0.15 | 0.5~1 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 8~10 | 0.9~1.1 | ≧ 380 | 590~760 | ≧ 18 | ||
| ≦ 0.15 | 0.5~1 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 8~10 | 0.9~1.1 | ≧ 380 | 590~760 | ≧ 18 | ||
| ≦ 0.15 | 0.5~1 | 0.3~0.6 | ≦ 0.03 | ≦ 0.03 | 8~10 | 0.9~1.1 | ≧ 380 | ≧ 585 | ≧ 20 | 179~217 | |
| ≦ 0.15 | 0.5~1 | 0.3~0.6 | ≦ 0.025 | ≦ 0.025 | 8~10 | 0.9~1.1 | ≧ 380 | 585~760 | ≧ 20 | ||
| ≦ 0.2 | 0.5~1 | 0.3~0.8 | ≦ 0.03 | ≦ 0.03 | 1~1.5 | 0.45~0.65 | ≧ 275 | 480~660 | ≧ 18 | ||
| 0.12~0.18 | 0.17~0.37 | 0.4~0.7 | ≦ 0.03 | ≦ 0.03 | 0.8~1.1 | 0.4~0.55 | ≧ 295 | ≧ 440 | ≧ 22 | ≧ 179 | |
| ≦ 0.2 | 0.5~1 | 0.3~0.8 | ≦ 0.03 | ≦ 0.03 | 1~1.5 | 0.45~0.65 | ≧ 275 | 480~660 | ≧ 18 | ||
| 0.1~0.2 | 0.5~1 | 0.3~0.8 | ≦ 0.04 | ≦ 0.04 | 1~1.5 | 0.45~0.65 | ≧ 275 | ≧ 485 | ≧ 20 | 143~207 | |
| 0.1~0.2 | 0.5~1 | 0.3~0.8 | ≦ 0.04 | ≦ 0.004 | 1~1.5 | 0.45~0.65 | ≧ 275 | 485~660 | ≧ 20 | ||
| 0.08~0.18 | ≦ 0.35 | 0.4~0.1 | ≦ 0.03 | ≦ 0.025 | 0.7~1.15 | 0.4~0.6 | ≧ 275 | 440~590 | ≧ 22 | 130~175 |
